10 Station “Special” Tooling / 20 Station “D” Tooling Tablet Press / Compression Machine

Name: 10 Station “Special” Tooling / 20 Station “D” Tooling Tablet Press / Compression Machine
Brand: 10 Station “Special” Tooling / 20 Station “D” Tooling Tablet Press / Compression Machine
Rating: 5 (8 reviews)

This Rotary Tablet Press is built as per the GMP directives with total robust construction.

This machine is useful for small to medium-batch-size production. Easy operation and maintenance of this machine make it very popular.

SALIENT FEATURES of 10 Station Tooling Tablet Press Machine

Square GMP Model
Heavy-duty construction of the machine with C.I body and C.I middle plate
This model is available in 10 stations of “Special” tooling/20 Station “D” tooling.
The Special tooling model of the machine is available with a Maximum Operating Pressure of 12 tons.
The Special tooling model of the machine is available with a Maximum Tablet Diameter of 50 mm.
Easy Cleaning & quick changeover of Dies & Punches
Phosphorus Bronze bush is provided in Turret and it is mounted on a Needle Roller bearing results easy & noiseless running of the machine.

Upper Punch penetration is provided as a standard feature
Upper-Pressure Roller & Lower pressure roller are made of OHNS material
A double-sided lifting cam is provided for safe movement of Upper punches.
Interlocking to all upper guards is provided as a safety feature
Electronics digital tablet counter / RPM meter is provided in the front control panel
Reverse-direction motion protection is provided to avoid major accidents

TECHNICAL SPECIFICATIONS

Number of Station	10	20
Type of Tooling	‘SPECIAL’	D
Output Tablets/Hour	12,000 (Maximum) @ 20 RPM	28,800 (Maximum) @ 24 RPM
Max. Operating Pressure	12 Tons	10 Tons
Max. Tablet Diameter	50 mm	25 mm
Net Weight	1200 Kg.	1100 Kg.
Gross Weight	1600 Kgs.	1500 Kgs.
Depth of fill	30 mm
Upper Punch Penetration	1.5 to 8 mm
Main Electric. Motor	5 HP, 415 Volts, 50 Hz
Overall Dimension (mm)	980 x 1020 x 1820

* Depending upon the tooling size, shape, and material characteristics
Note: We reserve right to change specifications without any prior notice.

Key Highlights Of Our Tablet Compression Machine

Upper Punch penetration is provided as a standard feature
The upper-pressure Roller & Lower pressure roller are made of OHNS material
A double-sided lifting cam is provided for safe movement of Upper punches.
Interlocking to all upper guards is provided as a safety feature
Electronics digital tablet counter / RPM meter is provided in the front control panel
Reverse-direction motion protection is provided to avoid major accidents

Why Choose Our 20-Station “D” Tooling Tablet Press Machine?

Our Tablet Press Machines are made with the best quality materials and are cost-effective. Both of the stations are able to produce 12,000 @20 RPM and 28,800 @24 RPM respectively. Our machines are versatile and suitable for a wide range of tablet formulations and also are easy to operate and maintain. Additionally, our tablet compression machines offer various features such as:

Finishing
Proper & precise assembling
Power efficiency
High durability
Low maintenance
Heavy duty work
Noice control
